US $13,599 - 17,999 / Set
Product Name: new products dtg printer digital numbering machine 3d printer |
| Port: | Shen Zhen |
|---|---|
| Supply Ability: | 600 Set/Sets per Week new products dtg printer digital numbering machine 3d prin |
| Payment Terms: | T/T,Western Union,MoneyGram |
| Packaging Details: | Foam strong cartons with 38*39*30cm |
|---|---|
| Delivery Details: | Shipped in 20 days after payment |
new products dtg printer digital numbering machine 3d printer
Company information:
Established in 2002, Yuxunda International Company Ltd. is a specialized manufactu
-rer which integrates R&D, production and marketing in the field of UV printer(SU6090,
SU1015,SU1315,SU2513), heat sublimation machine and printer consumables. In the
past 12 years and coming future, we just insist: QUALITY FIRST, CUSTOMER FOREMOST!
Product Description:
what the machine is used for? | |
Usage: | Metal/glass/ceramic/board/acrylic/pvc |
Product details: | |
Item no: | YXD -SU1015 |
Color: | gray and purple |
Working size: | 100*150cm |
Packing size: | 232*228*146cm |
Power: | 2500w |
Voltage: | 220V, 110V |
Gross Weight: | 450kg |
Printing Head | Epson DX5 |
Printing Color | High-precision intelligent double IV 4 colors/4 color(CMYK);8 colors/double 8colors(the white ink optional) |
Substrate Thickness | 80mm(130mm optional) |
Substrate Weight | Max 100KG |
Specifications of machine:
Model Type | SU1015-V01 |
Printing precision | 2880*1440dpi/32pass,1400*1440dpi/16pass,1440*720dpi/8pass,720*720dpi/4pass, 720*360dpi/2pass |
Lifting function | Intelligent ink cartridge lifting,electron automatic/manual operation intelligent induction to inspect and adjust height |
Receipt File Formats | TIFF(RGB&CMYK);BMP;PDF;EPS;JPEG |
Ink System | 500MLx8colors |
Print head quantity | 2 |
Printing Speed | 2Pass 21m^2/h |
4Pass 13m^2/h | |
8Pass 7.5m^2/h | |
16Pass 3.7m^2/h | |
32Pass 2.5m^2/h | |
Power Supply | AC220/110+/-10,50HZ~60HZ,1.5kW |
Printing interface | High-speed USB transmission interface |
Driving software | MicrosoftWindow98/Me/2000/XP/Win7 |
Working environment | Temperture15~35℃,Moisture20%~80% |
Packaging Dimension | 2320mm*2280mm*1460mm(L*W*H) |
Detail shows:
Device Features:
1.Employ imported linear guide rail,long service life,high stability,immensely decrease noise while printer is printing,reaches up to 40Db while printing.
2.Equipped with unique anti-collision system for print head,easiler to adjust by different media,avoid chance to damage print head by any misoperation.
3.Ink tank indicator lights-on when ink are lower than one third of capacity,guarantee a smooth production.
4.To better protect print head in easier way,avoid ink waste,save operation cost.
5.Ultraprint is a professional color management,evey printer is equipped a set of RIP software to ensure output effect and crease customer satisfaction.
6.Bidirectional printing,UV light curing alternately,improving printing speed and efficiency.
7.Size scale printed on working table,helping improve the speed and accuracy to place printing items.
Sample shows:
Our team and certification:
1.Which printing heads do you use :DX5 or DX7? ref?
print head:Two EPSON dx5 (Printing precision:2880dpi)
2.How do you clean the heads?
With our clean system(device).this device can do normal clean and Flash-spray clean which depends on different testing line we got and choose different cleaning way to reach best clean result and for saving ink too.
3.Which guarantee of the heads?
Print head is no guarantee, but we ensure will offer you official original print head. The mostimportant for print head is maintenance.We shall teach you how to maintenance and makemoisture to keep it for long time use cause we have a sutomatic wetting and cleaning system.
4. What type motor is used to drive the printer. Stepper motor or DC motor with encoder.
it is servo motor with encoder for X,Y axis and stepper motor for Z axis
5.Do you supply software for control of the hardware of the printer? (Not the RIP).
yes, another EXP software
6.What driver should we choose when using our RIP-software i.ex. Topaz RIP, Wasatch etc.
our RIP-Software is Ultra-Print,work on Microsoft Windows98/ME/2000/Win7,
7.Does the printing unit can move from one printing position to another a bit quicker?
yes,it can set three levels speed as LOW-MIDDLE-HIGH. it can makes the printer much efficient.
8.Any special stirring for white?
Yes, with stirring system for white there is a sensor inside of white ink bottle.
9.UV dryer: which type?
Double LED UV lamps
10.water cooled or not?
yes, Walter cooled
11.Output and quality of printing?
720*1440dpi/8pass 100% sure can output clear 3 fonts
Hot selling new products dtg printer digital numbering machine 3d printer
